Mechanical Parameters
Up/Down angle of swing arm:±30°
Table size :840mm*405mm
670mm*405mm
Table rotational angle:90°
Table sliding movement range:330mm
Angle of rotation for chair:±60°
Chair height adjustment range:460~600mm
Loading for chair:150kgs
Lifting height for pillow:≤150mm
Backrest obliquity:90°~135°
Electrical Parameters
Input voltage:110V/220V AC 50Hz~60Hz
Engine power:55W 220V AC
Light:16W 110V/220V AV
Fuse:5A 250V AC
No load power:1W
Pressure test:2KV
Main wire:10A 250V
Working mode:S1
Working temperature:-10℃~+40℃
Relative humidity:less than 90%
Installation Dimension
Figure size :1500mm*1000mm*1990mm
Weight:175kgs
