Mechanical Parameters
1.Up and down moving range:568~708mm
2.Chair rotation angle:0-270°
3.Backrest adjustment angle:80°-180°
4.Headrest adjustable in a semicircle area of 250mm radius
5.Chair max load:150kgs
Electrical Parameters
1.In voltage:100-115V AC 50Hz/60Hz
240V AC 50Hz/60Hz
2.Output voltage:100-115V AC 50Hz/60Hz
(The optional)240V AC 50Hz/60Hz
3.Engine power:28V 1.5A DC
4.Fuse:5A 130/250V AC
5.No load power:1W
6.Pressure test:2KV
7.Working mode:S1
8.Main wire:10A 120V/250V
9.Working temperature:-10℃~+40℃
10.Relative humidity:less than 90%
11.Figure size:1884mm*1316mm*1663mm
12.Weight:145kgs
Angle of rotation for chair:±60°
Lifting height for chair:460~600mm
Loading for chair:150kgs
Lifting height for pillow:≤150mm
Backrest obliquity:90°~135°
Input voltage:230V±10%
Engine power:140W
Fuse:5A 250V
Figure size:700mm*900mm*1400mm
Weight:60kgs
