Mechanical Parameters
Up/Down angle of swing arm:±30°
Angle of rotation for swing arm right-angle rack:360°
Angle of rotation for table:90°
Small tabletop slidable range:500mm
Chair height adjustment range:390~530mm
Loading for chair:150kgs
Electrical Parameters
Input voltage:110V/220V AC 50Hz~60Hz
Engine power:55W 24VDC 40W 30VDC
Light:18W 250V
Fuse:5A 250V AC
No load power:1W
Pressure test:2KV
Main wire:10A 250V
Working mode:S1
Working temperature:-10℃~+40℃
Relative humidity:less than 90%
Installation Dimension
Figure size :1550mm*1280mm*1900mm
Weight:210kgs
