Mechanical Parameters
Up/Down angle of swing arm:±30°
Table size :840mm*405mm
670mm*405mm
Table rotational angle:90°
Chair height adjustment range:450~590mm
Loading for chair:150kgs
Electrical Parameters
Input voltage:110V/220V AC 50Hz~60Hz
Engine power:55W 220V AC
Light:40W 110V/220V AV
Fuse:5A 250V AC
No load power:1W
Pressure test:2KV
Main wire:10A 250V
Working mode:S1
Working temperature:-10℃~+40℃
Relative humidity:less than 90%
Installation Dimension
Figure size :1190mm*1150mm*1990mm
Weight:150kgs
